provide standardized analog, unreinforced strain gauge bridge output signals in mV/V. As an option, many of our tension and compression force sensors can be supplied with an extended temperature range of -20°C up to 60°C.
Typical applications for these sensor types are for example, material testing machines, rope or elastic force measurement, examination of operating forces, determination of force in belt tensioners or bowden controls, industrial process monitoring at press-in, riveting, stamping, drawing operations.
Place of Origin Shanghai, China Brand Name NS Model Number NS-TH18 Type of Sensor LOAD CELL Rated Capacity 0~30 ton Output Signal 2.0mV/V, 0~5V, 0~10V, 4-20mA, RS485 etc. Accuracy ±0.03%F.S(typ.) Electrical Connection Flying lead or customized Mechanical Connection Bolt and Nut Power Supply 24 Vdc (connect to amplifier) Operational Mode vertical press force Measuring Medium vertical force from solid Material Stainless Steel Certificate Obtain RoHs,CE, ISO9001 certification Lead Time 2~3 weeks
Place of Origin Shanghai, China Brand Name NS Model Number NS-TH17 Type of Sensor LOAD CELL Rated Capacity 0~30 ton Output Signal 2.0mV/V, 0~5V, 0~10V, 4-20mA, RS485 etc. Accuracy ±0.03%F.S(typ.) Electrical Connection Flying lead or customized Mechanical Connection Bolt and Nut Power Supply 24 Vdc (connect to amplifier) Operational Mode vertical press force Measuring Medium vertical force from solid Material Stainless Steel Certificate Obtain RoHs,CE, ISO9001 certification Lead Time 2~3 weeks
·Scale manufacturers (platform scales) ·Medicine (weighing hospital patients) ·Building industry (weighing materials, power shovels)
Introduction of Load Cell
TH5 load cells are perfectly suited for use with any type of tank, batching or platform scales as well as for level monitoring - and are used by market leaders. Precise measurement results up to accuracy class C3 per OIML R60. The particularly robust TH5 load cells are available in standard dimensions and can be easily integrated and quickly adapted to the required maximum capacities ranging from 10 kg to 1000 kg TH7 bending beam is designed for heavier duty applications. Capacities extend to 1000kg ideal for IBC bag filling applications or more general purpose industrial weight measurement in process industries. All stainless steel and hermetically sealed is the ideal choice high accuracy industrial weighing machinery
Place of Origin Shanghai, China Brand Name NS Model Number NS-TH6 Type of Sensor LOAD CELL Rated Capacity 0~500 Kg Output Signal 2.0mV/V, 0~5V, 0~10V, 4-20mA, RS485 etc. Accuracy ±0.05%F.S(typ.) Electrical Connection Flying lead or customized Mechanical Connection Bolt and Nut Power Supply 24 Vdc (connect to amplifier) Operational Mode vertical press force Measuring Medium vertical force from solid Material Alloy Steel Certificate Obtain RoHs,CE, ISO9001 certification Lead Time 2~3 weeks
