It’s difficult to obtain an ideal accuracy if choosing range is not matched actual situation. For example, we don’t suggest use a 1000bar range of pressure sensor on measuring 1bar pressure, it would be better if you could use 10bar range instead of 1000bar. Therefore, choosing the right measurement range is very important and efficient for you. Three major factors must to be taken into account:
READ MORE
① Operating Pressure Range: Pressure measuring range the sensor can be safely operated. ② Operating Mode: Absolute pressure, or gauge pressure ③ Maximum Pressure or Burst Pressure: The maximum value of pressure that can be withstood by the sensor without damaging itself. If the applied pressure is more than this maximum pressure value, it might result in device failure or inaccurate signal output, even damage the sensor itself, which named burst pressure. ④ Output Type: It could be Ratio-metric mV, 4~20mA, 0.5Vdc~4.5Vdc, 0~5Vdc, 0~10Vdc, digital I2C and digital SPI. ⑤ Full Scale: Maximum pressure that the sensor can measure from zero pressure. ⑥ Operating Temperature Range: The temperature range the sensor can operate reliably and provide an accurate output signal.
READ MORE
Output types of pressure sensors include the following four types: ① Ratiometric Millivolt Output(mV): Pressure sensor with ratiometric millivolt output are widely used in many applications because of their cost-effective nature. The full scale output of a millivolt sensor is from 40mV（Min.）to 120mV(Max.); 70mV (Typ.) under power of 5VDC or Idd=1.5mA. The output is directly proportional to the excitation power. ② Current Loop Output(4~20mA): These are pressure sensors with a current output of 4-20 mA. Since this kind of signal outputs are not much affected by electrical noise, the signals can be transmitted over a long distance. ③ Analog Voltage Output(Vdc). These are pressure sensors with a voltage output of 0.5~4.5Vdc, 0~5Vdc, and 0~10Vdc etc, which could be easily read by PCL, controller or indicator. ④ Digital output: The output signal in the case of a digital signal of I2C, SPI with digital code for pressure output values.
