| Specifications | Technical Data | |||||||||
| Measuring ranges | 0~1.0…1.6…3.0…10…20… 40…50...60... 80…90…100MPa | |||||||||
| Overload pressures | 200%F.S 150%F.S 150%F.S | |||||||||
| Burst pressures | 500%F.S 300%F.S 200%F.S | |||||||||
| Operational Mode | Gauge Pressure, Absolute Pressure | |||||||||
| Measuring Media | Gases/liquids non-corrosive to stainless steel 304 and 316L | |||||||||
| Type | PNP or NPN | |||||||||
| Output signal | 4~20mA | |||||||||
| Operating voltage | 24VDC(±4VDC) | |||||||||
| Display | 4-digit LED | |||||||||
| Accuracy | ±0. 5%F. S(typ. ) | |||||||||
| Long-term drift | ≤±0. 3%FS/-(typ. ) | |||||||||
| Operating temperature range | -25~+80℃ | |||||||||
| Leakage current | ≤1mA | |||||||||
| Insulation resistance | ≥100MΩ(100VDC) | |||||||||
| Vibration resistance | IEC 60068-2-6 (5…2000Hz, 20g) | |||||||||
| Shock resistance | IEC 60068-2-27 (50g, 11ms) | |||||||||
| EMC proof | IEC 61000-6-2/3/4 | |||||||||
| Material | 304 | |||||||||
| IP protection | IP65 | |||||||||
