| Specifications | Technical Data | |||||||||
| Measuring ranges | 0～0.5...1.0...1.5...3...5MPaD | |||||||||
| Overload pressures | 200%F.S | |||||||||
| Burst pressures | 500%F.S | |||||||||
| Measuring Media | Air, hydraulic oil, lubricating oil, and other gases/liquids | |||||||||
| Output signal | PNP Normally Open, Normally Closed NPN Normally Open, Normally Closed | |||||||||
| Operating voltage | 24VDC(16~32VDC) | |||||||||
| Accuracy | ±0. 5%F. S(typ. ) ±1. 0%F. S(maximum value) | |||||||||
| Long-term drift | ≤±0. 2%FS/-(typ. ) | |||||||||
| Ambient temperature | -40~+85℃ | |||||||||
| Medium temperature | -30℃～100℃ | |||||||||
| Insulation resistance | ≥200MΩ/200VDC | |||||||||
| Vibration resistance | IEC 60068-2-6 (5…2000Hz, 20g) | |||||||||
| Shock resistance | IEC 60068-2-27 (50g, 11ms) | |||||||||
| EMC proof | IEC 61000-6-2/3/4 | |||||||||
| IP protection | IP65、IP67 | |||||||||
