NS-WY06
Used inaviation, Automationproduction line, industrial machinery,
metroandengineering vehiclesfields
High resolution, smooth movement, and strong anti-interference capability
Protection Rating: IP54
Analog output: 0~5V, 0~10V, 4~20mA, potentiometer, encoder
| Specifications | Technical Data | |||||||||
| Stroke length | 0~100…500…750…1000…1200mm | |||||||||
| Comprehensive accuracy | ±0.05%F.S，±0.1%F.S，±0.25%F.S | |||||||||
| Resolution | 0.03mm | |||||||||
| Outputwire | 2wires/3wires | |||||||||
| Output signal | 4~20mA, 0~5V, 0~10V, ±0~5V, ±0~10V, encoder, resistance | |||||||||
| Operating voltage | 24VDC (12~32VDC) | |||||||||
| Operating temperature | -30~80℃ | |||||||||
| Vibration proof | 10g(5…2000Hz) | |||||||||
| Strike proof | 50g(11ms) | |||||||||
| Displacmentspeed | ≤0.7m/s | |||||||||
| Insulationresistance | ≥100MΩ (500VDC) | |||||||||
| Endurance pressure | 35MPa/70MPa(Peak) | |||||||||
| Material | Aluminum Alloy Aluminium alloy | |||||||||
| Electrical connection | M16 4pinconnector/M12×1 4pinconnector/Direct Cable | |||||||||
| Ip protection | IP54 | |||||||||
