| Specifications | Technical Data | |||||||||
| Measuring ranges | -100kPa...0~1.0…1.6…3.0…10…20… 40…60…70… 80…90...100MPa | |||||||||
| Overload pressures | 200%F.S 150%F.S 120%F.S | |||||||||
| Burst pressures | 500%F.S 200%F.S 150%F.S | |||||||||
| Operational Mode | Gauge Pressure, Absolute Pressure | |||||||||
| Measuring Media | Gases/liquids non-corrosive to stainless steel 304 and 316L | |||||||||
| nherent frequency | ＞400KHZ | |||||||||
| Zero point output | ≤ 2mV | |||||||||
| Output signal | 100mV | |||||||||
| Operating voltage | 5VDC/10VDC | |||||||||
| Accuracy | ±0. 25%F. S(typ. ) | |||||||||
| Long-term drift | ≤±0. 1%FS/- | |||||||||
| Operating temperature range | -55~+150℃(Optional) | |||||||||
| Insulation resistance | ≥100MΩ(500VDC) | |||||||||
| Vibration resistance | IEC 60068-2-6 (5…2000Hz, 20g) | |||||||||
| Shock resistance | IEC 60068-2-27 (50g, 11ms) | |||||||||
| EMC proof | IEC 61000-6-2/3/4 | |||||||||
| Material | Stainless Steel | |||||||||
| IP protection | IP65 ( aviationconnector 4-pole male) IP67 (M12×1 connectorordirect cable) | |||||||||
