| Specifications | Technique data | |||||||||
| Fx、Fy、Fz | 50、100、800N | |||||||||
| Accuracy grade | 1.0%F.S | |||||||||
| Sensitivity | 1.0±0.3mV/V | |||||||||
| Non-linearity | ≤±1.0%F.S | |||||||||
| Hystersis | ≤±1.0%F.S | |||||||||
| Repeatability | ±0.5%F.S | |||||||||
| Creep | ±0.1%F.S/30min | |||||||||
| Crosstalk | ≤3%F.S | |||||||||
| Temperature sensitivity drift | 0.5%F.S/10℃ | |||||||||
| Zero point temperature drift | 0.5%F.S/10℃ | |||||||||
| Sampling frequency | 2000...3000Hz | |||||||||
| Resolution | 0.03%F.S | |||||||||
| Input resistance | 350...800Ω | |||||||||
| Output resistance | 350...800 Ω | |||||||||
| Insulation resistance | ≥5000MΩ | |||||||||
| Operating temperature | -30 ～ 85 ℃ | |||||||||
| Compensation temperature | 10～70℃ | |||||||||
| Safeoverload | 150%F.S | |||||||||
| Ultimateoverload | 200%F.S | |||||||||
| Reference excitation voltage | 5VDC | |||||||||
| Power supply voltage | 5~12VDC | |||||||||
| Electrical interface | mV/V/I/RS485/CAN/RS232/TCP/EtherCAT/USB | |||||||||
| Material | 铝合金/不锈钢 | |||||||||
| Surface treatment | 阳极化/电解抛光 | |||||||||
| IP protection | IP60 | |||||||||
