| Specifications | Technique data | |||||||||
| Fx、Fy、Fz | 100、200、500、1000N | |||||||||
| Accuracy grade | 0.5%F.S | |||||||||
| Sensitivity | 1.0±0.3mV/V | |||||||||
| Non-linearity | ≤±0.5%F.S | |||||||||
| Hystersis | ≤±0.5%F.S | |||||||||
| Repeatability | ±0.5%F.S | |||||||||
| Creep | ±0.1%F.S/30min | |||||||||
| Crosstalk | ≤1%F.S | |||||||||
| Temperature sensitivity drift | 0.3%F.S/10℃ | |||||||||
| Zero point temperature drift | 0.3%F.S/10℃ | |||||||||
| Sampling frequency | 1000Hz | |||||||||
| Resolution | 0.03%F.S | |||||||||
| Input resistance | 350...800Ω | |||||||||
| Output resistance | 350...800 Ω | |||||||||
| Insulation resistance | ≥5000MΩ | |||||||||
| Operating temperature | -40 ～ 85 ℃ | |||||||||
| Compensation temperature | 10～70℃ | |||||||||
| Safeoverload | 150%F.S | |||||||||
| Ultimateoverload | 300%F.S | |||||||||
| Reference excitation voltage | 5VDC | |||||||||
| Power supply voltage | 12~32VDC | |||||||||
| Electrical interface | mV/V/I/RS485/CAN/RS232/TCP/EtherCAT/USB | |||||||||
| Material | Aluminum Alloy / Stainless Steel | |||||||||
| Surface treatment | Anodizing / Electrolytic Polishing | |||||||||
| IP protection | IP65 | |||||||||
