NS-S2
precise, reliable, high repeatability
wide operating temperature range
wide operating frequency range
frequency range: 50~40KHz
measuring-surface pressure resistance: 10bar
strong environmental adaptability, high-temperature resistant, unaffected by vibration, oil resistant, dust resistant
| Specifications | Technical Data | |||||||||
| Output signal | PWM(PNP or NPN) or AC Signal | |||||||||
| Output Voltage | PWM(high level is5V±0. 5), AC Signal0. 5. . 30Vpp | |||||||||
| Detection Range | 0.5~4mm | |||||||||
| Speed Range | 50~40KHz | |||||||||
| Operating temperature | -55℃~125℃ | |||||||||
| Operating Humidity | <95%<> | |||||||||
| Sinusoidal vibration | 10g/57-2000HZ | |||||||||
| Impact resistance | 10g, 11ms, threemethoddirection | |||||||||
| IP protection | IP67 | |||||||||
| Detect object | ironmagnetic metal, Aluminum, Stainless Steel | |||||||||
