NS-WY08E
compact and lightweight structure, safe and reliable
non-contact measurement
Strong anti-interference capability
Protection rating IP67
Multiple signal outputs: 0 ~ 5V, 0 ~ 10V, 4 ~ 20mA, SSI,
RS485 (Mod Bus- RTU)
5000mmavailable with flexible Teflon probe rodto reachto20m
| Specifications | Technical Data | |||||||||
| Stroke length | 0~50…100…200…300…1000…5000mm | |||||||||
| Distinguishability | 0.005mm | |||||||||
| Nonlinearity | ±0.02%F.S | |||||||||
| Repeatability | 0.005mm | |||||||||
| Update time | ＜ 1 ms | |||||||||
| Fluctuation | ＜±0.01%F.S | |||||||||
| Output signal | 4~20mA，0~5V，0~10V，RS485，SSI | |||||||||
| Operating voltage | 24VDC | |||||||||
| Current consumption | 50-140mA(byRangedepending on) | |||||||||
| Electric shock | 500V(electrical groundandmachine ground) | |||||||||
| Medium temperature | -40~230℃(higherhightemperatureplease consult us) | |||||||||
| Ambient temperature | -40~70℃ | |||||||||
| Liquid material | SUS316L, titanium alloy, Teflonetc. | |||||||||
| Vibration proof | 20g(5…2000Hz) | |||||||||
| Strike proof | 100g | |||||||||
| Magnet speed | Any | |||||||||
| Endurance pressure | 35MPa/70MPa(Peak) | |||||||||
| Material | Sensorhead: 304Stainless SteelandAluminumformed; Sensorrod: 316Stainless Steel | |||||||||
| Ip protection | IP67 | |||||||||
