| Specifications | Technical Data | |||||||||
| Stroke length | 0~50…100…200…300…1000…4000mm | |||||||||
| Nonlinearity | ＜±0.02%F.S | |||||||||
| Repeatability | 0.002mm | |||||||||
| Update time | ＜ 1 ms | |||||||||
| Fluctuation | ＜±0.01%F.S | |||||||||
| Output signal | 4~20mA，0~5V，0~10V，Profibus，Modbus，CANOpen，SSI | |||||||||
| Operating voltage | 24V | |||||||||
| Current consumption | 70~90mA(byRangedepending on) | |||||||||
| Electric shock | 500V(electrical groundandmachine ground) | |||||||||
| Operating temperature | -40~75℃ | |||||||||
| Vibration proof | 12g / 10...2000Hz | |||||||||
| Strike proof | 100g | |||||||||
| Magnet speed | Any | |||||||||
| Endurance pressure | 35MPa/70MPa(Peak) | |||||||||
| Material | Aluminummaterial | |||||||||
| Electrical connection | M12×1 5 pin, M16×1 6 pin, Direct Cable | |||||||||
| Ip protection | IP67 | |||||||||
