NS-WY08G
Non-contact measurement
Linear accuracy up to 0. 02% F. S.
Multiple signal outputs: 0-5V, 0-10V 4-20mA, synchronous serial output with A/D conversion(SSI)
pressure resistance up to700bar, Protection rating IP67
Built into hydraulic cylinders for linear measurement with absolute output
Used in machinery and hydraulic/pneumatic transmission equipmentfields
| Specifications | Technical Data | |||||||||
| Stroke length | 0~50…100…200…300…1000…3000mm | |||||||||
| Nonlinearity | ＜±0.02%F.S | |||||||||
| Repeatability | 0.005mm | |||||||||
| Update time | ＜ 1 ms | |||||||||
| Fluctuation | ＜±0.01%F.S | |||||||||
| Output signal | 4~20mA，0~5V，0~10V，Profibus，Modbus，CANOpen，SSI | |||||||||
| Operating voltage | 24VDC | |||||||||
| Current consumption | 50-140mA(byRangedepending on) | |||||||||
| Electric shock | 500V(electrical groundandmachine ground) | |||||||||
| Operating temperature | -40~75℃ | |||||||||
| Vibration proof | 20g(5…2000Hz) | |||||||||
| Strike proof | 100g | |||||||||
| Magnet speed | Any | |||||||||
| Endurance pressure | 35MPa/70MPa(Peak) | |||||||||
| Material | Sensorhead: 304Stainless SteelandAluminumformed; Sensorrod: 316Stainless Steel | |||||||||
| Electrical connection | 6pinDINmale connector, Direct Cable | |||||||||
| Ip protection | IP67 | |||||||||
