NS-WY08R
Strong anti-interference capability
Protection rating IP67
Multiple signal outputs: 0~5V, 0~10V, 4~20mA,
RS-485, synchronous serial output with A/D conversion(SSI)
Can be installed inside hydraulic cylinders, with pressure resistance up to 700 bar
Used in machinery and hydraulic/pneumatic transmission equipment
| Specifications | Technical Data | |||||||||
| Stroke length | 0~50…100…200…300…1000…5000mm | |||||||||
| Nonlinearity | ＜±0.02%F.S | |||||||||
| Repeatability | 0.002mm | |||||||||
| Update time | ＜ 1 ms | |||||||||
| Fluctuation | ＜±0.01%F.S | |||||||||
| Output signal | 4~20mA，0~5V，0~10V，Profibus，Modbus，CANOpen，SSI | |||||||||
| Operating voltage | 24VDC | |||||||||
| Current consumption | 50-140mA(byRangedepending on) | |||||||||
| Electric shock | 500V(electrical groundandmachine ground) | |||||||||
| Operating temperature | -40~75℃ | |||||||||
| Vibration proof | 20g(5…2000Hz) | |||||||||
| Strike proof | 100g | |||||||||
| Magnet speed | Any | |||||||||
| Endurance pressure | 35MPa/70MPa(Peak) | |||||||||
| Material | Sensorhead: 304Stainless SteelandAluminumformed; Sensorrod: 316Stainless Steel | |||||||||
| Electrical connection | 6pinDINmale connector, Direct Cable | |||||||||
| Ip protection | IP67 | |||||||||
