NS-E
Used inpetrochemical, environmental protection, water conservancyfields
passedEMC, salt spray, temperature and humiditytesting
submersible type
full stainless-steel package
waterproof vented cable sealed to the housing
matched water-depth pressure gauges are available
| Specifications | Technical Data | |||||||||
| Measuring ranges | 0~0.5m…1m…10m…30m…50m…100m…150m…200mH2O | |||||||||
| Overload pressures | 200%F.S | |||||||||
| Burst pressures | 500%F.S | |||||||||
| Operational Mode | Gauge Pressure | |||||||||
| Measuring Media | water, oil | |||||||||
| Output signal | 4~20mA 0~5VDC 0~10VDC | |||||||||
| Operating voltage | 24VDC(12~32VDc) | |||||||||
| Accuracy | ±0.1%F.S ±0.25%F.S | |||||||||
| Long-term drift | ≤±0.15%F.S/ year（typ.） | |||||||||
| Compensated temperature range | -20~+80℃ | |||||||||
| Operating temperature range | -30~+80℃ | |||||||||
| Storage temperature range | -40~+120℃ | |||||||||
| Fluid temperature range | -30~+120℃ | |||||||||
| Insulation resistance | ≥100MΩ(100VDC) | |||||||||
| Vibration resistance | IEC 60068-2-6 (5…2000Hz, 20g) | |||||||||
| Shock resistance | IEC 60068-2-27 (50g, 11ms) | |||||||||
| EMC proof | IEC 61000-6-2/3/4 | |||||||||
| Material | Stainless Steel | |||||||||
| Ip protection | IP68 | |||||||||
