NS-E10
All‑titanium construction
IP68 protection rating
Suitable for corrosive liquids
| Specifications | Technique data | |||||||||
| Measuring ranges | 0.75mH2O~600mH2O | |||||||||
| Overload pressures | 150%F.S | |||||||||
| Burst pressures | 350%F.S | |||||||||
| Operational Mode | Gauge Pressure | |||||||||
| Measuring Media | water, oil | |||||||||
| Output signal | 4~20mA 0~5VDC 0~10VDC | |||||||||
| Operating voltage | mV Output：10VDC(2.5~12VDc) mA Output：9~30VDc | |||||||||
| Accuracy | ±0.1%F.S | |||||||||
| Long-term drift | ≤±0.1%F.S/ year（typ.） | |||||||||
| Compensated temperature range | -2~+30℃ | |||||||||
| Operating temperature range | -20~+60℃ | |||||||||
| Output impedance | 2KΩ | |||||||||
| Insulation resistance | ≥100MΩ(500VDC) | |||||||||
| Vibration resistance | IEC 60068-2-6 (5…2000Hz, 20g) | |||||||||
| Shock resistance | IEC 60068-2-27 (50g, 11ms) | |||||||||
| EMC proof | IEC 61000-6-2/3/4 | |||||||||
| Material | titanium | |||||||||
| Ip protection | IP68 | |||||||||
