Applications of torque sensor
·Scale manufacturers (platform scales, legal-for-trade scales)
·Medicine (weighing hospital patients)
·Building industry (weighing materials, power shovels)
·Agriculture (automatic feeders)
·Public sector (weighing garbage)
·Quality assurance
Introduction of torque sensor
Static torque sensor is ideal for use in static force measurement; It is available in seven maximum capacities, which range from 1 to 200 N.m, thus covering a very broad range, the product is widely used for industrial quality control system.
Special features of torque sensor
·Wide measuring range up to 200 N.m
·Excellent overload capacity
·High accuracy, anti-corrosion
Applications of torque sensor
·Scale manufacturers (platform scales, legal-for-trade scales)
·Medicine (weighing hospital patients)
·Building industry (weighing materials, power shovels)
·Agriculture (automatic feeders)
·Public sector (weighing garbage)
·Quality assurance
Introduction of torque sensor
Static torque sensor is ideal for use in static force measurement; It is available in seven maximum capacities, which range from 1 to 200 N.m, thus covering a very broad range, the product is widely used for industrial quality control system.
Special features of torque sensor
·Wide measuring range up to 200 N.m
·Excellent overload capacity
·High accuracy, anti-corrosion
Torque Sensor electric specification
Power supply: 5~24VDC
Various optional output signal: 1.0~1.5mV/V, (if connect with amplifier, 4~20mA, 0~± 5V, 0~± 10V etc)
Input resistance: 380±10Ω
Output resistance: 350±3Ω
Insulation resistance: 2000MΩ
Torque Sensor construction
Alloy steel
Specifications | Technical data |
Rated capacity | 1 2 5 10 20 50 200 N.m |
Output sensitivity | 1.5~1.5±0.002 mV/V |
Non-linearity | ≤±0.02 %F.S. |
Hystersis | ≤±0.02 %F.S. |
Repeatability | ≤±0.02 %F.S. |
Creep | ±0.02 %F.S./30min |
Temperature effect on output | ±0.05 %F.S./10℃ |
Temperature effect on zero | ±0.05 %F.S./10℃ |
Input resistance | 380±10 Ω |
Output resistance | 350±3 Ω |
Zero output | <±1 %F.S. |
Insulation resistance | ≥2000MΩ |
Operating temperature range | -25~+70 ℃ |
Safe overload | 150 %F.S |
Ultimate overload | 300 %F.S |
Recommended excitation voltage(without amplifier) | 5~12 Vdc |
Maximum excitation voltage(without amplifier) | 18 Vdc |
Material | Alloy steel |
IP protection | IP65 |
Torque Sensor electric specification
Power supply: 5~24VDC
Various optional output signal: 1.0~1.5mV/V, (if connect with amplifier, 4~20mA, 0~± 5V, 0~± 10V etc)
Input resistance: 380±10Ω
Output resistance: 350±3Ω
Insulation resistance: 2000MΩ
Torque Sensor construction
Alloy steel
Specifications | Technical data |
Rated capacity | 1 2 5 10 20 50 200 N.m |
Output sensitivity | 1.5~1.5±0.002 mV/V |
Non-linearity | ≤±0.02 %F.S. |
Hystersis | ≤±0.02 %F.S. |
Repeatability | ≤±0.02 %F.S. |
Creep | ±0.02 %F.S./30min |
Temperature effect on output | ±0.05 %F.S./10℃ |
Temperature effect on zero | ±0.05 %F.S./10℃ |
Input resistance | 380±10 Ω |
Output resistance | 350±3 Ω |
Zero output | <±1 %F.S. |
Insulation resistance | ≥2000MΩ |
Operating temperature range | -25~+70 ℃ |
Safe overload | 150 %F.S |
Ultimate overload | 300 %F.S |
Recommended excitation voltage(without amplifier) | 5~12 Vdc |
Maximum excitation voltage(without amplifier) | 18 Vdc |
Material | Alloy steel |
IP protection | IP65 |
Torque sensor dimensions:
Torque sensor dimensions:
Torque sensor order guide:
Torque sensor order guide:
